Products > Display Monitors > OPD-1190
19" SXGA Open Frame Display Monitor

Features:

Open frame supports analog VGA input
Multi scan functions
High luminance
OSD control on rear
Maximum colors of 262K
Backlight lifetime up to 50,000 hours
Optional DVI, Video or S-Video input
Auto recognition of input signal
AC Universal power input
                   About Aplex | News & Events | Products | Application | Service & Support | Global | Home
Copyright © 2005 - 2007  Aplex America, Inc.  All rights reserved.
Use of this  site indicates you accept the
Terms of Use.
Products
Industrial Panel Computer Company
Providing the latest industrial product information and solutions
Specifications
Display Specifications
Display
19" Color Active TFT Flat Panel Display
Luminance
250 cd/m2
Viewing Angle
140/140 degrees(H/V)
Resolution
1280 x 1024 (native mode), 262K colors
Backlight
50,000 hrs
Touch Screen
Resistive Antiglare (optional)
OSD Controls/Indicators
Automatic Screen, Setup (OSD), Brightness, Contrast, Horizontal /
Vertical Position, Image Lock, Color Balance, Video Information,
Power On and Sync detected

Power Input

AC 100~240V
Mechanical Specifications
Construction
Steel chassis & front panel
Dimensions
484(W) x 400(H) x 70.3(D) mm
Mounting
Panel Mount / Rack Mount (optional)
Environment Specifications
Operating Temperature
0 - 50 'C (32~122 'F)
Storage Temperature
-20 - 60 'C (-4 ~ 140 'F)
Relative Humidity
10-90% @40 'C Non-condensing, without touch screen
Vibration
1G peak, 5~500 Hz (Random)
Shock
15G peak acceleration (11 msec, duration)
Rating
NEMA 4/IP65
Certification
FCC, CE Class A certified
Data Sheet
Dimensions
