Products > AHM-6104
10.4" Industrial Fanless Touch Panel PC

Features:

10.4" TFT LCD supports 800 x 600 resolution
Fanless and CPU VIA Eden 400MHz/733MHz
NEMA 4 /IP65 compliant front panel
Sealed resistive touch screen
AC 100~240V power input
Support Panel / VESA 75 mount
                 About Aplex | News & Events | Products | Application | Service & Support | Global | Home
Copyright © 2005 - 2007  Aplex America, Inc.  All rights reserved.
Use of this  site indicates you accept the Terms of Use.
Products
Industrial Panel Computer Company
Providing the latest industrial product information and solutions
Specifications
Display Specifications
Display
10.4" SVGA TFT LCD 800 x 600
Luminance
250 cd/m2
Viewing Angle
120° (R/L)  110° (U/D)
Backlight
20,000 hours


General Specifications
Construction
Plastic molding front panel and metal housing
Front Panel Color
Black
CPU
VIA Eden 400MHz/ 733MHz
DRAM
256MB SDRAM up to 512MB
Storage
1 Compact Flash card slot, or space for 2.5" HDD and 1 CF card
slot
I/O Connectors
2 x Serial ports (COM1: RS-232, COM 2：RS-232 /422/485)
1 x Ethernet port (10/100 base-T)
2 x USB 1.1
1 x parallel port
1 x Stereo audio Mic-in, Line-in and Line-out;
1 x PS/2 keyboard & mouse
Touch Screen
4-wire ,analog resistive
Weight
4.3kgs/ 9.48lbs
Power Input
AC 100~240V
Dimensions
317(W) x 74(D) x 243(H) mm
Environment Specifications
Operating Temperature
0 - 50 'C
Storage Temperature
-20 - 60 'C
Relative Humidity
10-90% @ 40 'C Non-condensing
Vibration
5 - 17Hz, 0.1" double amplitude displacement
17 - 640Hz, 1.5G acceleration peak to peak
Shock
10 to 25Hz (X,Y,Z direction 2G, 30 minutes)
Shock
10G acceleration peak to peak (11ms)
Certification
FCC, CE Class A certified
Data Sheet
Dimensions
