Products > AHM-6101
10.4" RISC-based Human Machine Interface

Features:

10.4" TFT LCD with resolution of 800x600
Fanless Intel Xscale PXA255 CPU
NEMA 4/IP65 compliant front panel
DC 11~28V wide-range power input
Sealed resistive touch screen
CompactFlash Type I/II card
One Ethernet port 10/100 base-T supported
Win. CE net 4.2 / 5.0 OS support
                  About Aplex | News & Events | Products | Application | Service & Support | Global | Home
Copyright © 2005 - 2007  Aplex America, Inc.  All rights reserved.
Use of this  site indicates you accept the Terms of Use.
Products
Industrial Panel Computer Company
Providing the latest industrial product information and solutions
Specifications
Display Specifications
Display
10.4" SVGA TFT LCD
Luminance
250 cd/m2
Viewing Angle
130° (R/L) 110° (U/D)
Resolution
800x600
Backlight
20,000 hrs
General Specifications
Construction
Plastic molding front panel and metal housing
Front Panel Color
Black
CPU
Intel Xscale PXA255, 400MHz
Touch Screen
4-wire analog resistive
Power Input
DC 11V~28V
I/O Connectors
COM1（RS-232/422/485）
COM2（RS-232/）
PS/2 port for keyboard or mouse
USB Client 1.1 and Host 1.1
Ethernet port
External VGA port
Speaker out x 1/Mic-in x 1
CF slot
Memory Bank
128MB DRAM
1MB SRAM with battery backup
32MB Flash for operating system
CF slot for application software
Weight
4.3kg/9.48 lbs
Dimensions
317(W) x 50(D) x 243mm(H)
Environment Specifications
Operating Temperature
0 - 50 'C
Storage Temperature
-20 - 60 'C
Relative Humidity
10-90% @ 50 'C Non-condensing
Vibration
5 - 17Hz, 0.1" double amplitude displacement
17 - 640Hz, 1.5G acceleration peak to peak
Shock
10 to 25Hz (X,Y,Z direction 2G, 30 minutes)
Rating
NEMA 4/IP 65 compliant front panel
Certification
FCC, CE Class A certified
Data Sheet
Dimensions
