Products > AHM-6084
8" Industrial Fanless Touch Panel PC

Features:

8" High Brightness TFT LCD (400 cd/m2 )
Fanless and CPU VIA Eden 400MHz
Mini-PCI socket for WLAN solution (optional)
NEMA 4/IP 65 compliant front panel
Sealed resistive touch screen
DC 11~28V wide-range power input
Support Panel mount
                  About Aplex | News & Events | Products | Application | Service & Support | Global | Home
Copyright © 2005 - 2007  Aplex America, Inc.  All rights reserved.
Use of this  site indicates you accept the Terms of Use.
Products
Industrial Panel Computer Company
Providing the latest industrial product information and solutions
Specifications
Display Specifications
Display
8" SVGA TFT LCD 800 x 600
Pixel Pitch
0.204 (W) x 0.204 (H) mm
Viewing Angle
130°  (R/L)
Backlight
CCFL x 2 replaceable
Life-time 40, 000 Hours1024x768
Luminance
400 cd/m2
General Specifications
Construction
Plastic molding housing
Front Panel Color
Black
CPU
VIA Eden 400MHz
DRAM
256MB SDRAM up to 512MB
Storage
1 Compact Flash card slot, or space for 2.5" HDD and 1 CF card
slot
I/O Connectors
2 x Serial ports (COM 1：RS-232, COM 2：RS-232/422/485 )
1 x Ethernet port (10/100 Base-T)
2 x USB 1.1
1 x Parallel port
1 x Stereo audio Mic-in, Line-in and Line-out
1 x PS/2 keyboard & mouse
Touch Screen
4-wire ,analog resistive
Weight
2.41kgs
Power Input
11-28 VDC, 1.5A maximum at 24 VDC
Dimensions
231(W) x 74(D) x 176mm(H)
Environment Specifications
Operating Temperature
0 - 50 'C
Storage Temperature
-20 - 70 'C
Relative Humidity
10-90% @ 40 'C Non-condensing
Vibration
5 - 17Hz, 0.1" double amplitude displacement
17 - 640Hz, 1.5G acceleration peak to peak
Shock
10 to 25Hz (X,Y,Z direction 2G, 30 minutes)
Shock
10G acceleration peak to peak (11ms)
Certification
FCC, CE Class A certified
Data Sheet
Dimensions
