Products > AHM-6051
5.7" RISC-based Human Machine Interface

Features:

RISC-based and low-power consumption
Samsung ARM 2410 processor
5.7" QVGA (320x240) color TFT LCD
Onboard with 64MB DRAM and 64MB Flash
memory
Sealed resistive touch screen
Win. CE net 4.2 OS support
NEMA 4/IP65 compliant front panel
Specifications
Display Specifications
Display
5.7" QVGA TFT LCD
Luminance
500 cd/m2
Viewing Angle
130°  (R/L)
Resolution
320 x 240
Backlight
40,000 hrs
General Specifications
Construction
Plastic molding housing
Front Panel Color
Black
CPU
Samsung ARM 2410
Touch Screen
4-wire analog resistive
Power Input
DC 24V
I/O Connectors
COM1 (RS-232)
COM2 (RS-422/485)
USB Client 1.1 and Host 1.1
Ethernet port
Memory Bank
64MB DRAM / 64MB Flash for operating system
Weight
1.0kgs
Dimensions
204(W) x 46(D) x 149mm(H)
Environment Specifications
Operating Temperature
0 - 50 'C
Storage Temperature
-20 - 70 'C
Relative Humidity
10-90% @ 50 'C Non-condensing
Vibration
5 - 17Hz, 0.1" double amplitude displacement
17 - 640Hz, 1.5G acceleration peak to peak
Shock
10 to 25Hz (X,Y,Z direction 2G, 30 minutes)
Rating
NEMA 4/IP 65 compliant front panel
Certification
FCC, CE Class A certified
Data Sheet
Dimensions
