Products > Display Monitors > ADP-1150
15" Color TFT Industrial Display Monitor

Features:

15" TFT XGA LCD
1024(H) x 768(V), 400 cd/m2
Front panel NEMA 4/IP 65 rating
Wall-mount screw holes
Resistive touch screen (optional)
Optional DVI, Video or S-Video input
Optional stainless steel front bezel
Support a wide-ranging resolutions from
640 x 480 to up to 1600 x 1200 with auto phase
and auto position
                    About Aplex | News & Events | Products | Application | Service & Support | Global | Home
Copyright © 2005 - 2007  Aplex America, Inc.  All rights reserved.
Use of this  site indicates you accept the
Terms of Use.
Products
Industrial Panel Computer Company
Providing the latest industrial product information and solutions
Specifications
Display Specifications
Display
15" Color Active TFT Flat Panel Display
Luminance
400 cd/m2
Viewing Angle
140/125 (H/V)
Resolution
1024 x 768 (native mode), 16.2M colors
Backlight
50,000hrs
Touch Screen
Resistive Antiglare
OSD Controls/Indicators
Automatic Screen, Setup (OSD), Brightness, Contrast,
Horizontal/Vertical Position, Image Lock, Color Balance, Video
Information, Power On and Sync
Power Input
AC 100~240V
Mechanical Specifications
Construction
Steel chassis & front panel
Dimensions
410 (W) x 310 (H) x 69 (D) mm
Mounting
Panel Mount / Rack Mount (optional)
Environment Specifications
Operating Temperature
0 - 50 'C (32~122 'F)
Storage Temperature
-20 - 60 'C (-4 ~ 140 'F)
Relative Humidity
10-90% @40 'C Non-condensing, without touch screen
Vibration
1G peak, 5~500 Hz (Random)
Shock
15G peak acceleration (11 msec, duration)
Rating
NEMA 4/IP65
Certification
FCC, CE Class A certified
Data Sheet
Dimensions
